4 Channel Receiver – Fixed Code M4 433MHZ
R63,64
Package Includes
- 1x 4-Channel 433MHz Fixed Code M4 Receiver
Our Customer Guarantee:
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
Features / Specs
- Model: ZQD01
- Receiver IC: PT2272-M4 / SC2272-M4 (Remote Decoder Chip)
- Configuration: Manually Coded (Address selectable with solder jumpers)
- Address Code: 8-Bit (Up to 256 different address codes)
- Number of Channels: 4
- Output Type: Momentary
- Operating Voltage Range: 5.0VDC
- Operating Current (Typical): 4.0mA @ 5VDC
- Operating Frequency: 433MHz
- Modulation: ASK (Amplitude Shift Keying)
- Receiver Sensitivity: As low as -105dBm
