DC-DC Boost Converter – High Voltage
DC-DC Boost Converter – High Voltage - Image 2
DC-DC Boost Converter – High Voltage - Image 3

DC-DC Boost Converter – High Voltage

R180,18

Package Includes

  • 1x High Voltage DC-DC Boost Converter

Our Customer Guarantee:

  • Check Mark Satisfaction Guaranteed
  • Check Mark No Hassle Refunds
  • Check Mark Secure Payments
SKU: 8ME0600 Category:

Description

WARNING!!!
This module outputs lethal high voltages so extreme caution must be taken when using it. It is your responsibility to follow all the necessary safety precautions.

Features / Specs

  • Module Type: DC-DC Boost / Step-Up Converter (non-isolated)
  • Input Voltage: 10 – 32VDC
  • Output Voltage: 50 – 390VDC
  • Max Input Current: 5A
  • Max Output Current: 200mA
  • Output Power: 40W (Recommended); 70W (Peak)
  • Conversion Efficiency: 88%
  • Switching Frequency: 75kHz
  • Short circuit protection
  • Over-current protection – If input current exceeds 4.5A, output voltage will begin to drop
  • Over-voltage protection – Will not allow an output voltage greater than 410VDC
  • Input reverse polarity protection – Fuse will blow if powered up with reverse polarity
  • Operating Temperature: -40℃ to +85℃
